RobtoL & RobLion

Generator Set
HP5500 CEX-W

item ID:CEEP

Type			HP5500CXE-W		HP6500LN-W
Alternator	Generator	Rated frequency(Hz)	50	60	50	60
		Rated output(KW)	2.8	3.0	2.5	2.8
		Rated voltage(V)	220、230、240
		Power factor(cosφ)	1.0
	Welder	Voltage without load(V)	55-65
		Running voltage(V)	26
		Rated current(A)	160
		Current adjusting range(A)	50-180
		Continous loading ratio	40%
Engine		Welding stick(mm)	2-4
		Mode	HP186F(E)/HP186FA
		Type	Single-cylinder、 4-stroke、Vertical、 air-cooled 、Diesel engine
		Starting fashion	Manual or Electric Start
Generator Ser		Fuel tank capacity(L)	12.5
		Continuous running time(h)	6.5/5.5
		N.W./G.W.(kg)	100/104		185/190
		Overall dimension LxWxH(mm)	720x480x585		910x520x740
		Package size LxWxH(mm)	740x495x600		930x530x760

update: November. 5. 2011
