| Part No. |
D.R(mm) |
D.L(mm) |
d(mm) |
H2(mm) |
| RB01 |
4R |
4L |
57.50 |
27 |
RB02 |
5R |
5L |
57.50 |
27 |
RB03 |
5R |
5L |
70.00 |
35 |
RB04 |
6R |
6L |
57.50 |
27 |
RB05 |
6R |
6L |
70.00 |
35 |
RB06 |
7R |
7L |
57.50 |
27 |
RB07 |
7R |
7L |
70.00 |
35 |
RB08 |
8R |
8L |
57.50 |
27 |
RB09 |
8R |
8L |
70.00 |
35 |
RB10 |
9R |
9L |
57.50 |
27 |
RB11 |
9R |
9L |
70.00 |
35 |
RB12 |
10R |
10L |
57.50 |
27 |
RB13 |
10R |
10L |
70.00 |
35 |
RB14 |
12R |
12L |
57.50 |
27 |
RB15 |
12R |
12L |
70.00 |
35 |
RB16 |
14R |
14L |
57.50 |
27 |
RB17 |
14R |
14L |
70.00 |
35 |
RB18 |
15R |
15L |
57.50 |
27 |
RB19 |
15R |
15L |
70.00 |
35 |
RB20 |
16R |
16L |
57.50 |
27 |
RB21 |
16R |
16L |
70.00 |
35 |
USE : For drilling machines with chucks or adapters.
suitable for blind holes on solid wood and laminates.T.C.T with center
point and M5 x 10mm adjusting screw .10 x27mm or 10x30mm shank.
update: June.
23, 2011
|
