空压机	item ID:APAA
产品总数: 49	更新日期：2011-09-28

电动空气压缩机

	APAB Motor:0.75KG/1 HP Air Delivery:0.1m³/min Diameter(mm)xNo.:42x1 Pressure:0.7Mpa Tank:8L G.Weight:21KG Dimension:46x26x44CM
	APAC Motor:0.75KG/1 HP Air Delivery:0.1m³/min Diameter(mm)xNo.:42x1 Pressure:0.7Mpa Tank:6L G.Weight:21KG Dimension:47x21x47CM
	APAD Motor:0.75KG/1 HP Air Delivery:0.1m³/min Diameter(mm)xNo.:42x1 Pressure:0.7Mpa Tank:6L G.Weight:21KG Dimension:47x21x47CM
	APAE Motor:0.75KG/1 HP Air Delivery:0.1m³/min Diameter(mm)xNo.:42x1 Pressure:0.7Mpa Tank:6L G.Weight:21KG Dimension:47x21x47CM
	APAF Motor:1.5KW/2.5HP Air Delivery:0.12m³/min Diameter(mm)xNo.:47x1 Pressure:0.7Mpa Tank:24L G.Weight:28KG Dimension:42x40x60CM
	APAG Motor:1.5KW/2HP Air Delivery:0.12m³/min Diameter(mm)xNo.:47x1 Pressure:0.7Mpa Tank:24L G.Weight:27KG Dimension:60x31x58CM
	APAH Motor:1.5KW/2.5HP Air Delivery:0.12m³/min Diameter(mm)xNo.:47x1 Pressure:0.7Mpa Tank:12L G.Weight:26KG Dimension:47x39x45CM
	APAJ Motor:1.5KW/2HP Air Delivery:0.12m³/min Diameter(mm)xNo.:47x1 Pressure:0.7Mpa Tank:24L G.Weight:27KG Dimension:60x31x58CM
	APAK Motor:1.5KW/2HP Air Delivery:0.12m³/min Diameter(mm)xNo.:47x1 Pressure:0.7Mpa Tank:24L G.Weight:27KG Dimension:60x31x58CM
	APAL Motor:1.5KW/2HP Air Delivery:0.12m³/min Diameter(mm)xNo.:47x1 Pressure:0.7Mpa Tank:24L G.Weight:27KG Dimension:60x31x58CM

	APAM Motor:1.5KW/2HP Air Delivery:0.12m³/min Diameter(mm)xNo.:47x1 Pressure:0.7Mpa Tank:15L G.Weight:25KG Dimension:49x40x74CM
	APAN Motor:1.875KW/3HP Air Delivery:0.12m³/min Diameter(mm)xNo.:47x1 Pressure:0.7Mpa Tank:35L G.Weight:32KG Dimension:70x30x58CM
	APAP Motor:2.2KW/3HP Air Delivery:0.2m³/min Diameter(mm)xNo.:42x2 Pressure:0.7Mpa Tank:30L G.Weight:36KG Dimension:68x32x62CM
	APAQ Motor:1.5KW/2.5HP Air Delivery:0.12m³/min Diameter(mm)xNo.:47x1 Pressure:0.7Mpa Tank:50L G.Weight:35KG Dimension:80x31x57CM
	APAR Motor:1.5KW/2.5HP Air Delivery:0.12m³/min Diameter(mm)xNo.:47x1 Pressure:0.7Mpa Tank:50L G.Weight:27KG Dimension:80x32x67CM

[ Sub | Top ]

电动空气压缩机

	APAS Motor:0.25kw /1/3HP Air Delivery:0.032m³/min Diameter(mm)xNo.:32x1 Pressure:0.7Mpa Tank:4L G.Weight:10KG Dimension:47x21x41CM
	APAT Motor:1.5kw /2HP Air Delivery:0.198m³/min Diameter(mm)xNo.:61x1 Pressure:0.7Mpa Tank:25L G.Weight:24KG Dimension:60x30x59CM
	APAU Motor:4kw /5.5HP Air Delivery:0.6m³/min Diameter(mm)xNo.:90x2 Pressure:0.7Mpa Tank:172L G.Weight:200KG Dimension:153x60x105CM
	APAV Motor:7.5kw /10HP Air Delivery:1.0m³/min Diameter(mm)xNo.:90x3 Pressure:0.7Mpa Tank:230L G.Weight:10KG Dimension:168x73x122CM

[ Sub | Top ]

单级移动式冷风空气压缩机

	APAW Motor:2.2kw /3HP Air Delivery:0.25m³/min Diameter(mm)xNo.:60x2 Pressure:0.7Mpa Tank:200L G.Weight:144KG Dimension:81x61x162CM
	APAX Motor:2.2kw /4HP Air Delivery:0.36m³/min Diameter(mm)xNo.:65x2 Pressure:0.7Mpa Tank:80L G.Weight:111KG Dimension:98x49x84CM
	APAY Motor:3.0kw /3HP Air Delivery:0.25m³/min Diameter(mm)xNo.:60x2 Pressure:0.7Mpa Tank:200L G.Weight:144KG Dimension:81x61x162CM
	APAZ Motor:0.55kw /0.75HP Air Delivery:0.036m³/min Diameter(mm)xNo.:51x1 Pressure:0.7Mpa Tank:24L G.Weight:42KG Dimension:64x36x58CM
	APBA Motor:0.75kw /1HP Air Delivery:0.08m³/min Diameter(mm)xNo.:51x2 Pressure:0.7Mpa Tank:40L G.Weight:65KG Dimension:90x46x69CM
	APBC Motor:1.5kw /2HP Air Delivery:0.10m³/min Diameter(mm)xNo.:65x1 Pressure:0.7Mpa Tank:35L G.Weight:65KG Dimension:77x44x71CM
	APBD Motor:1.1kw /1.5HP Air Delivery:0.12m³/min Diameter(mm)xNo.:51x2 Pressure:0.7Mpa Tank:40L G.Weight:65KG Dimension:90x46x69CM
	APBE Motor:1.5kw /2HP Air Delivery:0.17m³/min Diameter(mm)xNo.:51x2 Pressure:0.7Mpa Tank:62L G.Weight:77KG Dimension:98x47x77CM
	APBF Motor:2.2kw /3HP Air Delivery:0.25m³/min Diameter(mm)xNo.:65x2 Pressure:0.7Mpa Tank:96L G.Weight:102KG Dimension:114x49x87CM
	APBG Motor:3kw /4HP Air Delivery:0.36m³/min Diameter(mm)xNo.:65x3 Pressure:0.7Mpa Tank:103L G.Weight:118KG Dimension:121x49x89CM

	APBH Motor:4kw /5.5HP Air Delivery:0.48m³/min Diameter(mm)xNo.:90x2 Pressure:0.7Mpa Tank:120L G.Weight:172KG Dimension:140x60x96CM
	APBJ Motor:5.5kw /7.5HP Air Delivery:0.67m³/min Diameter(mm)xNo.:80x3 Pressure:0.7Mpa Tank:120L G.Weight:200KG Dimension:142x60x98CM
	APBK Motor:7.5kw /10HP Air Delivery:0.9m³/min Diameter(mm)xNo.:90x3 Pressure:0.7Mpa Tank:172L G.Weight:233KG Dimension:153x60x105CM
	APBL Motor:11kw /15HP Air Delivery:1.4m³/min Diameter(mm)xNo.:100x3 Pressure:0.7Mpa Tank:230L G.Weight:336KG Dimension:173x72x122CM
	APBM Motor:15kw /20HP Air Delivery:1.9m³/min Diameter(mm)xNo.:120x3 Pressure:0.7Mpa Tank:295L G.Weight:450KG Dimension:189x77x138CM

[ Sub | Top ]

电动压缩机系列

APBN

Motor:2.4HP
Air Delivery:0.15m³/min
Diameter(mm)xNo.:47x1
Pressure:0.7Mpa
Tank:35L
G.Weight:35KG
Dimension:68x35x72.5CM

Motor:6.5HP
Air Delivery:0.25m³/min
Diameter(mm)xNo.:65x2
Pressure:0.7Mpa
Tank:32L
G.Weight:65KG
Dimension:102x60x80CM

Motor:5.5HP
Air Delivery:0.25m³/min
Diameter(mm)xNo.:65x2
Pressure:0.7Mpa
Tank:100L
G.Weight:82KG
Dimension:114x49x92CM

[ Sub | Top ]

双级移动式冷风空气压缩机

	APBS Motor:4KW/5.5HP Air Delivery:0.40m³/min Diameter(mm)xNo.:65x1/90x1 Pressure:1.25Mpa Tank:120L G.Weight:150KG Dimension:138x54x96CM
	APBT Motor:1.5KW/2HP Air Delivery:0.15m³/min Diameter(mm)xNo.:65x1/51x1 Pressure:1.25Mpa Tank:62L G.Weight:76KG Dimension:89x48x84CM
	APBU Motor:2.2KW/3HP Air Delivery:0.20m³/min Diameter(mm)xNo.:65x1/51x1 Pressure:1.25Mpa Tank:96L G.Weight:102KG Dimension:114x48x86CM
	APBV Motor:3KW/4HP Air Delivery:0.30m³/min Diameter(mm)xNo.:65x1/51x1 Pressure:1.25Mpa Tank:103L G.Weight:126KG Dimension:114x48x86CM
	APBW Motor:7.5KW/10HP Air Delivery:0.71m³/min Diameter(mm)xNo.:90x2/80x1 Pressure:1.25Mpa Tank:172L G.Weight:220KG Dimension:153x60x105CM
	APBX Motor:11KW/15HP Air Delivery:1.05m³/min Diameter(mm)xNo.:90x1/100x2 Pressure:1.25Mpa Tank:230L G.Weight:315KG Dimension:173x72x122CM
	APBY Motor:15KW/20HP Air Delivery:1.5m³/min Diameter(mm)xNo.:120x2/100x1 Pressure:1.25Mpa Tank:295L G.Weight:430KG Dimension:189x77x138CM
	APBZ Motor:5.5KW/7.5HP Air Delivery:0.53m³/min Diameter(mm)xNo.:80x2/65x1 Pressure:1.25Mpa Tank:120L G.Weight:186KG Dimension:136x54x96CM

[ Sub | Top ]

新型的单级移动式冷风空气压缩机

	APCA Motor:4kw /5HP Air Delivery:0.6m³/min Diameter(mm)xNo.:95x2 Pressure:0.8Mpa Tank:172L G.Weight:168KG Dimension:150x55x106CM
	APCB Motor:7.5kw /10HP Air Delivery:1.2m³/min Diameter(mm)xNo.:95x3 Pressure:0.8Mpa Tank:300L G.Weight:300KG Dimension:186x73x120CM
	APCD Motor:5.5kw /7.5HP Air Delivery:0.75m³/min Diameter(mm)xNo.:95x2 Pressure:0.8Mpa Tank:172L G.Weight:178KG Dimension:150x55x106CM
	APCE Motor:11kw /15HP Air Delivery:1.6m³/min Diameter(mm)xNo.:95x4 Pressure:0.8Mpa Tank:300L G.Weight:345KG Dimension:186x72x127x73x122CM

[ Sub | Top ]
