RobtoL & RobLion

发动机
HP188F(E)

item ID:CEED

Model	168F(E)	200F(E)	173F(E)	177F(E)	182F(E)	188F(E)	190F(E)
Type	Single-cylinder、 4-stroke、 air-cooled 、OHV 、GASOline ENGINE
Bore x stroke(mm)	68x45	68x54	73x58	77x58	82x64	88x64	90x66
Displacement(ml)	163	196	242	270	337	389	420
Compression Ratio	8.5:1	8.5:1	8.2:1	8.2:1	8:1	8:1	8.5:1
Rated output(KW/3600rpm)	3.3	4	5.1	5.8	7	7.7	8.5
Max torque(N·m/2500rpm)	9	11	15	17	22	24	26.5
lgnition fashion	Zero touch point、 Transistor(CDI)
Starting fashion	Manual or Electric Start
Fuel tank capacity(L)	3.6	3.6	6.0	6.0	6.5	6.5	6.5
Oil capacity(L)	0.6	0.6	1.1	1.1	1.1	1.1	1.1
Fuel consumption(g/KW·h)	≤313
Oil consumption(g/KW·h)	6.8
Fuel trademark	90#un leaded gasoline
Oil trademark	10W30SAE
Continuous running time(h)	2.5	2.0	2.65	2.35	2.1	1.9	1.9
Overall dimension LxWxH(mm)	365x320x360	365x320x360	450x465x480	480x465x490	480x465x490	480x465x490	480x465x490
N.W./G.W.(kg)	15/17	16/18	25/27	26/28	31/33	32/34	32/34
