RobtoL & RobLion

发电机组
HP7500CXE-3

item ID:CEEV

Type		HP4000CXE-3		HP7500CXE-3		HP12000LN-3
Alternator	Rated frequency(Hz)	50	60	50	60	50	60
	Rated output(KW)	2.8	3.0	5.2	5.8	8.8	9.5
	Max output(KW)	3.0	3.3	5.8	6.5	10	10.5
	Rated voltage(V)	220/380、 230/400
	Power factor(cosφ)	0.8
ENGINE	Mode	HP178F(E)/FA(E)		HP188F(E)		HP2V86FE
	Type	Single-cylinder、 4-stroke、Vertical、 air-cooled 、Diesel ENGINE
	Starting fashion	Manual or Electric Start
Generator Ser	Fuel tank capacity(L)	12.5 16
	Continuous running time(h)	9.0	8.0	7.5	6.3	7.5	6.3
	N.W./G.W.(kg)	74/78		190/195		245/265
	Overall dimension LxWxH(mm)	680x460x560		910x520x740		850x620x720
	Package size LxWxH(mm)	700x480x580		930x530x760		870x630x740

2011年11月5日
