水泵机组
HP50D(E)

item ID:CEFV

Type		HP50D(E)	HP80D(E)	HP100D(E)
Pump	inch	2"	3"	4"
	Rated head(m)	15	13	16
	Max.suction head(m)	8	8	8
	Rated capacity(m3/h)	22	30	40
	Self-priming time(s/4m)	80	120	180
	Mode	HP170F(E)	HP178(E)	HP186F(E)
ENGINE	Type	Single Cylinder、 4-stroke、 air- cooled 、Vertical、GasolineENGINE
	Starting fashion	Manual Electric Start
	Fuel tank capacity(L)	2.5	3.5	5.5
水泵机组	Continuous running time(h)	2.5	2.0	2.0
	N.W./G.W.(kg)	35/38	52/55	69/72
	Overall dimension LxWxH(mm)	520x450x610	560x450x660	655x470x690
	Package size LxWxH(mm)	540x465x630	575x470x680	665x490x715
