HP80Q(E)

Type		HP50Q(E)	HP80Q(E)	HP100Q(E)
Pump	inch	2"	3"	4"
	Rated head(m)	15	13	16
	Max.suction head(m)	8	8	8
	Rated capacity(m3/h)	22	30	40
	Self-priming time(s/4m)	80	120	180
	Mode	HP168F-A	HP168F-B	HP173F
ENGINE	Type	Single Cylinder、 4-stroke、 air- cooled 、OHV 、GasolineENGINE
	Starting fashion	Manual or Electric Start
	Fuel tank capacity(L)	3.6	3.6	6
水泵机组	Continuous running time(h)	2.5	2.0	2.65
	N.W./G.W.(kg)	26/29	30/33	46/49
	Overall dimension LxWxH(mm)	470x365x370	515x365x415	645x470x600
	Package size LxWxH(mm)	490x380x385	535x385x440	680x490x640
