TECHNICAL DATA(50HZ) |
| GENSET MODEL |
HP-Y8 |
HP-Y10 |
HP-Y12 |
HP-Y16 |
HP-Y20 |
HP-Y25 |
| DIESEL ENGINE MODEL |
YSAD385G |
YD480G |
Y485G |
YSD490G |
Y4100G |
Y4102G |
| ENGINE Characters |
Water-cooled,in line,4-cylinders,4-cycle,direct injection,1500rpm |
| Bore/Stroke(mm) |
80/90 |
80/90 |
85/90 |
90/100 |
100/115 |
102/118 |
| Rated output(KW) |
10 |
13.5 |
16 |
21 |
25 |
30 |
| Fuel Consumption(g/kw.hr) |
＜247 |
＜250.2 |
＜248.9 |
＜247.5 |
＜237 |
＜238 |
| Lube Consumption (g/kw.hr) |
＜2.72 |
| Compression ratio |
18 |
| Staring model |
Electric(12V) |
| ALTERNATOR MODEL |
HP-8KW |
HP-10KW |
HP-12KW |
HP-16KW |
HP-20KW |
HP-25KW |
| Rated power(KW) |
8 |
10 |
12 |
16 |
20 |
20 |
| Voltage(V) |
400/230 |
400/230 |
400/230 |
400/230 |
400/230 |
400/230 |
| Current(A) |
14.4/34.8 |
18/43.5 |
21.7/52.2 |
27.1/65.2 |
36/86.7 |
43/108 |
| Frequrncy(HZ) |
50 |
| Power factor(cosφ) |
0.8/1.0 |
| Dimensions(LxWxH)mm |
1760x800x950 |
1860x800x950 |
1860x880x950 |
2050x880x1050 |
2150x880x1050 |
2250x1050x1300 |
| Net Weight(kg) |
650 |
700 |
750 |
800 |
900 |
950 |
TECHNICAL DATA(60HZ) |
GENSET MODEL |
HP-Y8 |
HP-Y10 |
HP-Y12 |
HP-Y16 |
HP-Y20 |
HP-Y24 |
DIESEL ENGINE MODEL |
YSAD380G |
Y385G |
YD480G |
Y485G |
YSD490G |
Y4100G |
ENGINE Characters |
Water-cooled,in line,4-cylinders,4-cycle,direct injection,1800rpm |
Bore/Stroke(mm) |
80/90 |
80/90 |
80/90 |
85/90 |
90/100 |
100/105 |
Rated output(KW) |
12 |
14 |
17 |
19 |
25 |
30 |
Fuel Consumption(g/kw.hr) |
＜247 |
＜262.5 |
＜250.2 |
＜248.9 |
＜247.5 |
＜237 |
Lube Consumption (g/kw.hr) |
＜2.72 |
Compression ratio |
18 |
Staring model |
Electric(12V) |
ALTERNATOR MODEL |
HP-8KW |
HP-10KW |
HP-12KW |
HP-15KW |
HP-20KW |
HP-24KW |
Rated power(KW) |
8 |
10 |
12 |
15 |
20 |
24 |
Voltage(V) |
400/230 |
400/230 |
400/230 |
400/230 |
400/230 |
400/230 |
Current(A) |
14.4/34.8 |
18/43.5 |
21.7/52.2 |
27.1/52.2 |
36/86.7 |
43.1/104 |
Frequrncy(HZ) |
60 |
Power factor(cosφ) |
0.8 |
Dimensions(LxWxH)mm |
1760x800x950 |
1760x800x950 |
1860x880x950 |
1860x880x950 |
2050x880x1050 |
2150x880x1050 |
Net Weight(kg) |
650 |
700 |
750 |
800 |
900 |
1000 |
