Model |
HP-W20 |
HP-W24 |
HP-W30 |
HP-W40 |
HP-W50 |
HP-W75 |
HP-W100 |
HP-W120 |
HP-W140 |
Rated Power(kw) |
20/40 |
24/38 |
30/35 |
40/46 |
50/56 |
75/83 |
100/108 |
120/126 |
140/150 |
ENGINE |
Model |
495D |
K4100D |
495ZD-1 |
R4100ZD1 |
R4105ZD1 |
R6105ZD-1 |
R6105AZLD-1 |
R6105ZLD |
R61131ZLD |
| Rated output(kw) |
26.5 |
30.1 |
36 |
47 |
56 |
84 |
110 |
132 |
155 |
| Fuel Consumption |
251 |
243 |
230 |
| Intaking method |
Natural apirated |
Turbocharged |
Turbocharged |
| Crankshaft rotation direction |
Counterclockwise(face to output end) |
| Govering method |
Mechanical |
| Speed(r/min) |
1500/(1800) |
| Cooling Starting Method |
Close water cooled/electric starting |
| GENERATOR |
Model |
HP-20 |
HP-24 |
HP-30 |
HP-40 |
HP-50 |
HP-75 |
HP-100 |
HP-120 |
HP-140 |
| Rated output/kw(KVA) |
20(25) |
24(30) |
30(37.5) |
40(50) |
50(62.5) |
75(94) |
100(125) |
120(150) |
140(175) |
| Rated Current(A) |
36 |
43.2 |
54 |
72 |
90 |
135 |
180 |
216 |
252 |
| Rated Voltage(V) |
400V/230W |
| Frequency(HZ) |
50/60Hz |
| Power Factor (cosφ) |
0.8(lagging) |
| Phase/Connection |
3-phase 4-wire aY type connection |
| Excitation |
Harmoinc Excitation or Phase Compound or Brushless |
| Voltage Regulation |
Manual/Automatic |
Net Weight(kg) |
750 |
800 |
860 |
980 |
1050 |
1260 |
1370 |
1460 |
1690 |
Packing size LWH(com) |
178x75x115 |
178x75x115 |
195x80x119 |
195x80x135 |
195x85x135 |
245x90x140 |
250x90x145 |
260x90x145 |
280x110x155 |
