RobtoL & RobLion

大机组
康明斯系列

item ID:CEGM

Model		HP-C40	HP-C75	HP-C80	HP-C90	HP-C120	HP-C150	HP-C170	HP-C180
Rated Power(kw)		40	75	80	90	120	150	170	180
ENGINE	Model	4BT3.9G	6BT5.9G	6BT5.9G1	6BTA5.9G2	6BTAA5.9G	6CBTAA8.3G	6CTAA8.3G	6CTAA8.3-G
	Rated output(kw)	50	86	92	102	132	163	183	200
	Max output(kw)	55	93	100	110	140	180	205	215
	Governing method	Mechanical/Electronical		Electronical
	Intaking method	Turbocharged
	Oil volume	9.5	14.3		16	23.8	26
	Displacement(L)	3.2	5.88			8.3
	Cylinder numbers	4	6
	Fuel consumption(g/kw.h)	≤210
	Cooling Starting Method	Closed water Cooled/electric starting
GENERATOR	Model	HP-40	HP-75	HP-80	HP-90	HP-120	HP-150	HP-170	HP-180
	Rated output/kw(KVA)	40(50)	75(94)	80(100)	90(112.5)	120(150)	150(187.5)	170(212.5)	180(225)
	Rated Current(A)	72	135	144	162	216	270	306	324
	Rated Voltage(V)	400/230
	Frequency(HZ)	50/60
	Power Factor (cosφ)	0.8lagging
	Phase/Connection	3-phase 4-wire aY type connection
	Excitation	Harmoinc Excitation or Phase Compound or Brushless
	Voltage Regulation	Manual/Automatic
Net Weight(kg)		830	1390	1460	1530	1700	1900	2300	2400
Packing size LWH(com)		179x70x133	210x70x138				228x83x153	252x85x165

Specifications given herein are subject to change without notice
