Model

HP-D24

HP-D30

HP-D50

HP-D75

HP-D100

HP-D120

ENGINE

Enginge Model

D226B-3D

TD226B-3D

TD226B-4D

TD226B-6D

TBD226B-6D

TBD226B-6D/13023811

Rated output(KW)

30

40

60

90

120

132

Max output(KW)

33

45

66

99

132

145.2

Starting method

Electric starting

Coolong method

Closed water cooled

Governing method

Machanical

Intaking method

Turbocharged

Turbocharged

Clinder numbers

3

4

6

Fuel consumption(g/kkkw.h)

≤208

≤205

Bore/stroke(mm)

105/120

Dispkacement(L)

3.12

4.16

6.23

Oil volume(L)

7.25

13

Type

Water cooling,in-line,four-stroke,humid sylinder liner,direct injection

Crankshaft rotation direction

Counterclockwise(face to output end)

GENERATOR

Model

HP-24

HP-30

HP-50

HP-75

HP-100

HP-120

Rated output(Kw)(kVA)

24(30)

30(37.5)

50(62.5)

75(94)

100(125)

120(150)

Rated Voltage(V)

Rated Current(A)

43.2

54

90

135

180

216

Frequency(Hz)

50/60

Power Factor (cosφ)

0.8lagging

Phase/Connection

3-phase 4-wire aY type connection

Excutation

Harmoinc Brushless Exciton

Voltage Regulation

Manual/Autmatic

Net Weight(kg)

650

660

800

1300

1450

1600

Packing Size LxWxH(cm)

168x70x150

168x70x150

200x70x150

245x90x170

250x90x185

260x90x185
