Morse Taper Mount:
| Model |
mm |
inch |
Taper mount |
mm |
mm |
KG |
Key |
| 22506 |
0.6-6 |
1/64-1/4 |
B10 |
29 |
51.5 |
0.102 |
Q10 series |
22510 |
1.0-10 |
1/32-3/8 |
B12 |
33 |
58 |
0.152 |
Q10 series |
22513 |
1.5-13 |
1/16-1/2 |
B16 |
42 |
71 |
0.246 |
Q13 series |
22513A |
1.5-13 |
1/16-1/2 |
B12 |
42 |
71 |
0.305 |
Q13 series |
22516 |
3.0-16 |
1/8-5/8 |
B16 |
52 |
87 |
0.479 |
Q16 series |
22516A |
3.0-16 |
1/8-5/8 |
B18 |
52 |
87 |
0.625 |
Q16 series |
22516D |
1.5-16 |
1/32-5/8 |
B16 |
52 |
90 |
0.625 |
Q16 series |
22516D |
1.5-16 |
1/32-5/8 |
B18 |
52 |
90 |
0.625 |
Q16 series |
22516R |
3.0-16 |
1/8-5/8 |
B16 |
52 |
93 |
0.650 |
Q16 series |
22516R |
3.0-16 |
1/8-5/8 |
B18 |
52 |
93 |
0.650 |
Q16 series |
Jacquard Taper Mount:
| Model |
mm |
inch |
Taper mount |
mm |
mm |
KG |
Key |
| 22613 |
1.5-13 |
1/16-1/2 |
JT33 |
42 |
71 |
0.305 |
Q13 series |
| 22616 |
3.0-16 |
1/8-5/8 |
JT6 |
52 |
87 |
0.625 |
Q16 series |
| 22616A |
3.0-16 |
1/8-5/8 |
JT33 |
52 |
87 |
0.625 |
Q16 series |
| 22616B |
3.0-16 |
1/8-5/8 |
JT6 |
52 |
87 |
0.625 |
Q16 series |
Thread Mount:M/UNF
| Model |
mm |
inch |
Taper mount |
mm |
mm |
KG |
Key |
| 23506 |
0.6-6 |
1/64-1/4 |
3/8-24UNF |
29 |
51.5 |
0.104 |
Q10 series |
| 23510 |
1.0-10 |
1/32-3/8 |
3/8-24UNF |
33 |
60 |
0.152 |
Q10 series |
| 23510A |
1.0-10 |
1/32-3/8 |
1/2-20UNF |
33 |
60 |
0.160 |
Q10 series |
| 23510D |
1.0-10 |
1/32-3/8 |
3/8-24UNF |
33 |
60 |
0.160 |
Q13 series |
| 23610 |
1.0-10 |
1/32-3/8 |
M12X1.25 |
33 |
60 |
0.160 |
Q10 series |
| 23513 |
1.5-13 |
1/16-1/2 |
1/2-20UNF |
42 |
71 |
0.305 |
Q13 series |
| 23513A |
1.5-13 |
1/16-1/2 |
3/8-24UNF |
42 |
71 |
0.305 |
Q13 series |
| 23516 |
3.0-16 |
1/8-5/8 |
1/2-20UNF |
52 |
87 |
0.625 |
Q16 series |
| 23516A |
3.0-16 |
1/8-5/8 |
5/8-16UNF |
52 |
87 |
0.625 |
Q16 series |
| 23616 |
3.0-16 |
1/32-5/8 |
M12X1.25 |
52 |
87 |
0.625 |
Q16 series |
|
