Morse Taper Mount:
| Model |
mm |
inch |
Taper mount |
mm |
mm |
KG |
Key |
82106 |
0.6-6 |
1/64-1/4 |
B10 |
31.5 |
49 |
0.125 |
Z06 series |
| 82110 |
1.0-10 |
1/32-3/8 |
B12 |
43 |
68 |
0.315 |
Z10 series |
82113 |
1.0-13 |
1/32-1/2 |
B16 |
53 |
84 |
0.598 |
Z13 series |
82113A |
1.0-13 |
1/32-1/2 |
B18 |
53 |
84 |
0.598 |
Z13 series |
82116 |
3.0-16 |
1/8-5/8 |
B16 |
57 |
89 |
0.713 |
Z13 series |
82116A |
3.0-16 |
1/8-5/8 |
B18 |
57 |
89 |
0.713 |
Z13 series |
82116D |
1.0-16 |
1/32-5/8 |
B16 |
57 |
95 |
0.776 |
Z13 series |
82120 |
5.0-20 |
3/16-3/4 |
B22 |
65 |
106 |
1.100 |
Z20 series |
Jacquard Taper Mount:
| Model |
mm |
inch |
Taper mount |
mm |
mm |
KG |
Key |
82206 |
0.6-6 |
1/64-1/4 |
JT1 |
31.5 |
49 |
0.125 |
Z06 series |
| 82210A |
1.0-10 |
1/32-3/8 |
JT2 |
43 |
68 |
0.315 |
Z10 series |
| 82213 |
1.0-13 |
1/32-1/2 |
JT6 |
53 |
84 |
0.598 |
Z13 series |
82213A |
1.0-13 |
1/32-1/2 |
JT33 |
53 |
84 |
0.598 |
Z13 series |
82216 |
3.0-16 |
1/8-5/8 |
JT3 |
57 |
89 |
0.713 |
Z13 series |
82216A |
3.0-16 |
1/8-5/8 |
JT6 |
57 |
89 |
0.713 |
Z13 series |
82220 |
5.0-20 |
3/16-3/4 |
JT3 |
65 |
106 |
1.100 |
Z20 series |
Thread Mount:UNF
| Model |
mm |
inch |
Taper mount |
mm |
mm |
KG |
Key |
83106 |
0.6-6 |
1/64-1/4 |
3/8-24UNF |
31.5 |
49 |
0.125 |
Z06 series |
| 83110 |
1.0-10 |
1/32-3/8 |
3/8-24UNF |
43 |
68 |
0.315 |
Z10 series |
| 83110C |
1.0-10 |
1/32-3/8 |
3/8-24UNF |
35 |
57 |
0.180 |
Z10 series |
83113B |
1.0-13 |
1/32-1/2 |
1/2-20UNF |
43 |
74 |
0.330 |
Z13 series |
83113 |
1.0-13 |
1/32-1/2 |
1/2-20UNF |
53 |
84 |
0.598 |
Z13 series |
83116 |
1.0-16 |
1/32-5/8 |
1/2-20UNF |
57 |
92 |
0.713 |
Z13 series |
|
