| Product Type |
XYLP70 |
XYLP80 |
XYLP90 |
XYLP110 |
XYLP150 |
XYLP170 |
XYLP170A |
Hole diameter (mm)
|
76 |
83 |
90.100.130 |
110.123 |
155.165 |
175.185 |
175.185 |
| Out diameter (mm) |
65 |
72 |
80 |
98 |
136.5 |
156 |
159 |
over all long (mm) |
811 |
795 |
795 |
838 |
904 |
1022 |
1033 |
| Weight (kg) |
13.5 |
18 |
21 |
36 |
85 |
102 |
119 |
Air press (kg/cm2) |
5-7 |
5-7 |
5-7 |
5-7 |
5-7 |
5-7 |
5-7 |
| Air consumption (m3/min) |
4 |
5.5 |
7.2 |
12 |
15.9 |
18 |
18 |
single energy (kgm)
|
7 |
8.1 |
11 |
18 |
34 |
44 |
50 |
| impacting frequncy (times/minute)
|
810 |
800 |
820 |
830 |
800 |
790 |
85 |
apply to
rock drill |
CIR70-18 |
QT80 |
|
CIR110-16A.CIR110-16B |
CIR150-17A.CIR150-17B |
CIR170-17A.CIR170-17B |
CIR170-17A.CIR170-17B |
| adaptor type |
conical: 48.8 *4.2 |
surface: 48*10*2 |
surface: T48*10*2 |
inside: AP12-2/8'' |
inside: T75*10*2.5 |
surface: T100*28*10 |
surface: T100*28*10 |
| Product Type |
XYHM3.5 |
XYHM4 |
XYHM5 |
XYHM5.5 |
XYHM6 |
Hole diameter (mm) |
90 |
105,115 |
140 |
140 |
152,165 |
| Out diameter (mm) |
79 |
98 |
122 |
124 |
136 |
over all long (mm) |
972 |
1038 |
1254 |
1214 |
1450 |
| Weight (kg) |
29.5 |
45 |
90 |
84 |
126 |
Air press (kg/cm2) |
7-21 |
7-21 |
7-21 |
7-21 |
7-21 |
| Air consumption (m3/min) |
4.3-14.2 |
3.5-18 |
6.5-21 |
7-21 |
8.5-25 |
single energy (kgm) |
20.9 |
30.4 |
65.1 |
68 |
82.2 |
| impacting frequncy (times/minute) |
950-1500 |
810-1500 |
850-1510 |
820-1550 |
820-1475 |
apply to
rock drill |
DHD3.5-18A |
DHD340A-15A.DHD340A-15B |
DHD350C-19A |
XY140 |
DHD360-19A.DHD360-19B |
| adaptor type |
surface:2-3/8'' |
surface:API2-3/8'' |
surface:API2-3/8'' |
surface:API2-3/8''.API3-1/2'' |
surface:API3-1/2'' |
|
